However, traditional asphalt mixtures often face challenges such as ageing, cracking, deformation and reduced performance under heavy traffic loads and extreme weather conditions.
To overcome these limitations, researchers have turned to modifying asphalt using different additive materials. These additives, which improve the physical and mechanical properties of binder and asphalt mixtures, include fibres, polymers, and nanomaterials (NM).
WHY IS MODIFICATION OF ASPHALT NEEDED?
The increased traffic volumes, larger and heavier trucks, and higher tyre pressures result in increased severity of the condition upon the pavement system, resulting in rutting, stripping and fatigue cracking.
In addition to this, the various events associated with climate change affect the selection and specifications of pavement materials and ultimately affect the pavement performance. The modification of bitumen binders with nanomaterials is essential because it significantly enhances their properties.
Nanomaterials, such as nano-clays, nano-silica, carbon nanotubes, and graphene, are incorporated into bitumen to improve its performance. Due to their small particle size and high surface area, these nanomaterials
IMPROVEMENT IN RUTTING AND FATIGUE RESISTANCE
The incorporation of nanomaterials in asphalt binders has shown promising results in enhancing rutting and fatigue resistance.
The Multiple Stress Creep Recovery (MSCR) test and the Linear Amplitude Sweep (LAS) test, essential for evaluating these properties, indicate that Nano-modified asphalts exhibit superior performance compared to traditional binders.
Carbon nanotubes, for instance, increase the stiffness and elasticity of asphalt binders, providing better resistance to the stresses imposed by heavy traffic loads. This leads to pavements.
SELF-HEALING PROPERTIES
An inventive method for extending the lifespan and durability of asphalt pavements is the use of nanomaterials in self-healing bitumen. Bitumen is enhanced in its ability to heal itself by the addition of nanomaterials.
including graphene oxide, silica nanoparticles, carbon nanotubes (CNTS), and nano clays. Bitumen is better able to redistribute heat and re-bond at the molecular level when cracks form because of these nano materials that increase the thermal conductivity, mechanical strength, and viscoelastic qualities.
This improvement makes it easier for bitumen to heal naturally and seal voids and cracks more successfully, prolonging the life of asphalt surfaces and lowering maintenance expenses.
ENVIRONMENTAL BENEFITS
Nanotechnology also offers environmental benefits by contributing to more sustainable asphalt production and usage.
The use of nanomaterials can lower the required temperature for asphalt mixing and compaction, reducing energy consumption and greenhouse gas emissions.
Nano-enhanced asphalt can incorporate recycled materials more effectively, promoting the reuse of waste products and reducing the demand for virgin resources.
HOW NANOTECHNOLOGY WORKS?
The bulk material's physical characteristics are significantly altered by the interaction of the nanoparticles with conventional materials. Because the nanomaterials have highly reactive isolated sites, they can alter the bulk material's electrical properties, changing its physical characteristics.
In order to create nanocomposites, it is necessary to comprehend how fundamental changes in physical properties can be used to modify the materials' properties. Because the following characteristics do not exist in a macro environment, nanomaterials differ from macro materials in these respects.
NANOMATERIALS FOR THE ROAD SECTOR
Nano materials are characterised based on origin (natural and artificial), i.e., Natural Nano material- a nanomaterial developed through mechanical means.
It has no direct or indirect link to anthropogenic activity or processes, Engineered/ artificial nano materials.
A nanomaterial conceived, designed, and intentionally produced by humans. Based on structural configuration (organic, inorganic, metal-based, metal oxide-based and carbon-based) -Carbon-based nanomaterials are materials composed primarily of carbon atoms with structural features at the nanometer scale ( to 100 nanometers).
1-dimensional - This class of nanomaterials has one dimension of the nanostructure that is outside the non-metric range (>10 nm), while two of the three dimensions (x, y) are in the nanoscale range.
2-dimensional - 2D nanomaterials have plate-like shapes with two dimensions outside the nanometer range, but 1D (3) is at the nanoscale (between l and 100 nm).
3-dimensional - Three-dimensional nanomaterials are materials that are not limited to the nanoscale in any dimension or range of dimensions.
There are different nanomaterials used in road construction.
LABORATORY CHARACTERIZATION OF NANOMATERIALS FOR PAVEMENT APPLICATIONS
A thorough testing and characterisation is necessary for a comprehensive understanding of the properties and behaviour of different nanomaterials for pavement applications.
The properties of nanomaterials depend on their particle size, shape, surface area and surface chemistry. Different characterisation techniques such as Scanning Electron Microscopy (SEM), Energy Dispersive X-ray (EDX).
Transmission Electron Microscopy (TEM), X-Ray Diffraction (XRD), and Fourier Transform Infrared (FTIR) spectroscopy can be employed to analyse the particle size, shape, surface morphology, structure and chemical composition of nanomaterials.
In addition to this, the rheological properties are characterised using a Dynamic Shear Rheometer (DSR) and a Bending Beam Rheometer (BBR). This helps in understanding the viscoelastic properties of nanomaterials modified asphalt.
Full Article Can be Downloaded
Article Published on: Equipment Times
Author : Samiksha Panthi
